# Bailey Steel Bridge: An Excellent Choice for Modern Engineering
In the field of modern bridge construction and emergency rescue, Bailey Steel Bridge stands out with its unique advantages and becomes an indispensable and important role. Made of high-strength steel, it has excellent load-bearing capacity and can easily cope with various complex terrains and different load requirements. Whether it is heavy vehicle traffic or large-scale material transportation, it can ensure stability and reliability, providing solid guarantee for smooth traffic.
The modular design of Bailey Steel Bridge is a highlight. Its components are produced in a standardized manner, with uniform size and strong interchangeability. No complex processing is required for on-site installation. It only needs to be assembled according to the design drawings, which greatly shortens the construction period. This efficient assembly method enables Bailey Steel Bridge to be quickly put into use in a short time in emergency situations, such as road rush after natural disasters and rapid construction of projects, so as to gain valuable time for rescue and security work.
It has strong adaptability and can be flexibly arranged in complex natural environments such as mountains, rivers, wetlands, and narrow spaces in cities. At the same time, Bailey steel bridges are highly reusable, and the disassembled components can be properly preserved and used in subsequent projects, realizing the recycling of resources, reducing long-term use costs, and complying with environmental protection concepts.
In addition, Bailey steel bridges also have good wind resistance and earthquake resistance, which can effectively resist the invasion of natural disasters such as severe weather and earthquakes, ensuring the safety and stability of bridges under extreme conditions. Its surface has undergone special anti-corrosion treatment, strong durability, long service life, and reduced later maintenance costs and frequency.
In short, Bailey steel bridges have shown great application value in the field of bridge construction with their excellent bearing capacity, efficient assembly efficiency, strong environmental adaptability and good durability. It is an indispensable and efficient solution in modern engineering, providing strong support for various traffic needs and emergency rescue tasks, and helping the stable development of society and the convenience and smoothness of people's lives.
Specifications:
| CB321(100) Truss Press Limited Table |
| No. |
Lnternal Force |
Structure Form |
| Not Reinforced Model |
Reinforced Model |
| SS |
DS |
TS |
DDR |
SSR |
DSR |
TSR |
DDR |
| 321(100) |
Standard Truss Moment(kN.m) |
788.2 |
1576.4 |
2246.4 |
3265.4 |
1687.5 |
3375 |
4809.4 |
6750 |
| 321(100) |
Standard Truss Shear (kN) |
245.2 |
490.5 |
698.9 |
490.5 |
245.2 |
490.5 |
698.9 |
490.5 |
| 321 (100) Table of geometric characteristics of truss bridge(Half bridge) |
| Type No. |
Geometric Characteristics |
Structure Form |
| Not Reinforced Model |
Reinforced Model |
| SS |
DS |
TS |
DDR |
SSR |
DSR |
TSR |
DDR |
| 321(100) |
Section properties(cm3) |
3578.5 |
7157.1 |
10735.6 |
14817.9 |
7699.1 |
15398.3 |
23097.4 |
30641.7 |
| 321(100) |
Moment of inertia(cm4) |
250497.2 |
500994.4 |
751491.6 |
2148588.8 |
577434.4 |
1154868.8 |
1732303.2 |
4596255.2 |
| CB200 Truss Press Limited Table |
| NO. |
Internal Force |
Structure Form |
| Not Reinforced Model |
Reinforced Model |
| SS |
DS |
TS |
QS |
SSR |
DSR |
TSR |
QSR |
| 200 |
Standard Truss Moment(kN.m) |
1034.3 |
2027.2 |
2978.8 |
3930.3 |
2165.4 |
4244.2 |
6236.4 |
8228.6 |
| 200 |
Standard Truss Shear (kN) |
222.1 |
435.3 |
639.6 |
843.9 |
222.1 |
435.3 |
639.6 |
843.9 |
| 201 |
High Bending Truss Moment(kN.m) |
1593.2 |
3122.8 |
4585.5 |
6054.3 |
3335.8 |
6538.2 |
9607.1 |
12676.1 |
| 202 |
High Bending Truss Shear(kN) |
348 |
696 |
1044 |
1392 |
348 |
696 |
1044 |
1392 |
| 203 |
Shear Force of Super High Shear Truss(kN) |
509.8 |
999.2 |
1468.2 |
1937.2 |
509.8 |
999.2 |
1468.2 |
1937.2 |
| CB200 Truss Press Limited Table |
| NO. |
Internal Force |
Structure Form |
| Not Reinforced Model |
Reinforced Model |
| SS |
DS |
TS |
QS |
SSR |
DSR |
TSR |
QSR |
| 200 |
Standard Truss Moment(kN.m) |
1034.3 |
2027.2 |
2978.8 |
3930.3 |
2165.4 |
4244.2 |
6236.4 |
8228.6 |
| 200 |
Standard Truss Shear (kN) |
222.1 |
435.3 |
639.6 |
843.9 |
222.1 |
435.3 |
639.6 |
843.9 |
| 201 |
High Bending Truss Moment(kN.m) |
1593.2 |
3122.8 |
4585.5 |
6054.3 |
3335.8 |
6538.2 |
9607.1 |
12676.1 |
| 202 |
High Bending Truss Shear(kN) |
348 |
696 |
1044 |
1392 |
348 |
696 |
1044 |
1392 |
| 203 |
Shear Force of Super High Shear Truss(kN) |
509.8 |
999.2 |
1468.2 |
1937.2 |
509.8 |
999.2 |
1468.2 |
1937.2 |
Advantage
Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity
